Notes:
1. The EAGLE 5 ISS can contain a maximum of 4000 connections (association – application server assignments).
2. The default value for the adapter parameter is m2pa.
3. A maximum of 32 IPSG M2PA or M 3UA associations can be assigned to the IPSG card.
4. The value of the lhost, rhost, or alhost parameters is a text string of up to 60 characters, with the first character being a
letter. The command line on the terminal can contain up to 150 characters. If the host names are too long to fit on the ent-
assoc command line, perform the chg-assoc command with the parameters and values necessary to complete the entry of the
IPSG M2PA association .
5. To activate the association after the association is assigned to a signaling link , the association must contain values for the
lhost, rhost, lport, and rport parameters.
6. If the lhost and alhost parameters are specified, the lhost parameter value represents the IP address corresponding to one
of the network interfaces (A or B) on the IP card while the alhost parameter value represents the IP address corresponding to
the other network interface of the same IP card.
7. The m2patset parameter can be specified only with the adapter=m2pa parameter.
8. The m2patset parameter value defaults to M2PA timer set 1 (m2patset=1) if the m2patset parameter is not specified.
9. When the adapter=m2pa parameter is specified, the RFC M2PA version is assigned to the M 2PA association by default . If
you wish to assign the Draft 6 M2PA version to this association , perform the Changing the Attributes of an IPSG Association"
procedure in this chapter after this procedure is completed to change the M2PA version of this association .
Sheet 4 of 4

Figure 98: Adding an IPSG M2PA Association

910-6278-001 Revision A, January 2012
IPSG M2PA and M3UA Configuration Procedures
From
Sheet 3
Enter the
ent-assoc command with these mandatory parameters.
:aname=<association name>
:lhost = <local host name from the
rtrv-ip-host output>
and with at least one of these optional parameters:
:lport = <local port ID>
:rhost = <remote host name>
:rport = <remote port ID>
:adapter = m2pa
:alhost = <alternate local host name from the rtrv-ip-host
output>
:m2patset = 1-20
(See Notes 1 through 9)
Enter the rtrv-assoc command
with this parameter.
:aname=<the name of the
association specified with the
ent-assoc command>
Enter the
chg-db:action=backup:dest=fixed
command.
742
