Routing keys can be fully or partially specified, or specified by default.
Full Routing Keys
For this routing application, all applicable fields in the Message Signaling Unit (MSU) must match the
contents of the full routing key.
SS7 message parameters are used to search for a match for full routing keys for each of the functions
supported by the ss7ipgw and ipgwi applications (IPGWx functionality).

Table 4: SS7 Full Routing Keys per IPGWx Functionality

IPGWx Functionality
(ANSI and ITU)
SCP connectivity via TCAP-over-IP
SEP connectivity via ISUP-over-IP
SEP connectivity via Q.BICC-over-IP
SEP connectivity via TUP-over-IP (ITU only)
SCP/SEP connectivity via non-ISUP, non-SCCP,
non-Q.BICC, non-TUP-over-IP
* The service indicator value of 4 can be used in this instance if the DPC is an ANSI point code.
910-6278-001 Revision A, January 2012
Table 4: SS7 Full Routing Keys per IPGWx Functionality
Destination Point Code
Service Indicator (=3)
Subsystem Number
Destination Point Code
Service Indicator (=5)
Originating Point Code
CIC Range Start
CIC Range End
Destination Point Code
Service Indicator (=13)
Originating Point Code
CIC Range Start
CIC Range End
Destination Point Code
Service Indicator (=4)
Originating Point Code
CIC Range Start
CIC Range End
Destination Point Code
Service Indicator (any value other than 3, 4*, 5,
and 13)
