3B-15 Differential:

Rear Differential Symptom Diagnosis

Condition
Gear noise
Bearing noise
Oil leakage

4WD Control Symptom Diagnosis

Diagnose 4WD system after performing the following inspections.
• Perform 4WD control system check referring to "4WD Control System Check".
Condition
4WD system does not
operate
Noise
Possible cause
Deteriorated or water mixed lubricant
Inadequate or insufficient lubricant
Maladjusted backlash between drive
bevel pinion and gear
Improper tooth contact in the mesh
between drive bevel pinion and gear
Loose drive bevel gear securing bolts
Damaged differential gear(s) or
differential pinion(s)
(Constant noise) Deteriorated or water
mixed lubricant
(Constant noise) Inadequate or
insufficient lubricant
(Noise while coasting) Damaged
bearing(s) of drive bevel pinion
(Noise while turning) Damaged
differential side bearing(s) or axle
bearing(s)
Clogged breather plug
Worn or damaged oil seal
Excessive oil
Loose differential carrier bolts
Possible cause
2WD/4WD switch faulty
Coupling air temperature sensor faulty
Coupling assembly faulty
Wiring or grounding faulty
4WD control module faulty
MAF sensor faulty
Accelerator pedal position (APP) sensor
faulty
CKP sensor faulty
Front and/or rear wheel speed sensor
faulty
Steering angle sensor faulty
ABS / ESP® control module faulty
ECM faulty
Damaged or worn bearing(s)
Correction / Reference Item
Repair and replenish referring to "Rear
Differential Oil Change".
Repair and replenish referring to "Rear
Differential Oil Change".
Adjust as prescribed referring to "Rear
Differential Disassembly and Reassembly".
Adjust or replace referring to "Rear Differential
Disassembly and Reassembly".
Replace or retighten referring to "Rear
Differential Disassembly and Reassembly".
Replace referring to "Rear Differential
Inspection".
Repair and replenish referring to "Rear
Differential Oil Change".
Repair and replenish referring to "Rear
Differential Oil Change".
Replace referring to "Rear Differential
Inspection".
Replace referring to "Rear Differential
Inspection".
Clean.
Replace.
Adjust oil level referring to "Rear Differential Oil
Change".
Replace or retighten.
Correction / Reference Item
Check switch referring to "2WD/4WD Switch
Inspection".
Check coupling air temperature sensor
referring to "Coupling Air Temperature Sensor
Inspection".
Check coupling assembly referring to
"Coupling Assembly Inspection".
Repair as necessary.
Check 4WD control module referring to
"Inspection of 4WD Control Module and Its
Circuits".
Check MAF sensor and its circuit.
Check accelerator pedal position (APP) sensor
and its circuit.
Check CKP sensor and its circuit.
Check front and/or rear wheel speed sensor
and its circuit.
Check steering angle sensor and its circuit.
®
Check ABS / ESP
control module and its
circuit.
Check ECM and its circuit.
Refer to "Rear Differential Inspection".
S7RW0A3204010
S7RW0A3204011
