4C-1 Rear Brakes:

Rear Brakes

Brakes

Rear Drum Brake Components

15
(a)
17
14
F
1. Brake drum
2. Brake shoe
3. Shoe return spring
4. Brake adjuster
5. Antirattle spring
6. Hold down spring
7. Shoe hold down pin
8. Push nut
9. Brake shoe lever

Repair Instructions

16
(b)
18
10. Wheel cylinder
11. Brake back plate
12. Rear wheel hub
13. Nut (4WD model)
14. Parking cable
15. Rear wheel hub mounting bolt
16. Wheel cylinder mounting bolt
17. Rear axle
18. Plug
11
12
(c)
19
10
13
(d)
1
7
19. Bleeder plug
: 73 N⋅m (7.3 kgf-m, 53 lb-ft)
: 12 N⋅m (1.2 kgf-m, 9.0 lb-ft)
: 7 N⋅m (0.7 kgf-m, 5.0 lb-ft)
: 175 N⋅m (17.5 kgf-m, 127.0 lb-ft)
: Heat-resistant brake grease
: Do not reuse.
: Apply brake fluid
F: Forward
S7RW0A4306001
4
2
8
5
9
3
6
I6RW0D430001-01
