Ignition System Components Location

NOTE
The figure shows left-hand steering vehicle. For right-hand steering vehicle, parts with (*) are installed
at the opposite side.
5
16
3
1. ECM
2. Ignition coil assembly for No.1 and No.4 spark plugs
3. Ignition coil assembly for No.2 and No.3 spark plugs
4. CMP sensor (VVT model)
5. CKP sensor
6. MAP sensor (if equipped)

Component Location

6
11
10
7. ECT sensor
8. MAF and IAT sensor
9. Electric throttle body assembly
10. High-tension cords
11. Knock sensor
12. Data link connector
8
9
4
7
2
Ignition System:
S7RW0A1803001
12*
15*
I5RW0C180002-01
13. Battery fuse box
14. Relay box
15. Junction block assembly
16. CMP sensor (VVT model)
1H-3
13
14
1
