Transfer Output Retainer Assembly
Disassembly and Reassembly
Disassembly
1) Uncaulk transfer output flange nut.
2) Remove transfer output flange nut while holding
flange (1) by using special tool.
Special tool
(A): 09930–40113
(A)
3) Remove transfer output flange (1) by bearing puller
(2).
4) Drive out bevel pinion (1) from transfer output
retainer by tapping it with plastic hammer (2).
2
1
S7RW0A3306009
1
I5RW0A330030-01
2
1
I5RW0A330031-01
I3RH01332019-01
5) Drive out front taper roller bearing (1) from bevel
pinion (3) by using bearing puller (2) and hydraulic
press.
2
6) Remove oil seal (1) by using special tool.
Special tool
(A): 09913–50121
1
7) Remove rear taper roller bearing (1), pump seal (3)
and spacers (2).
1
8) Drive out outer races (2) (front and rear) by using
brass bar (1).
1
Transfer:
3C-10
3
1
I5RW0A330032-01
(A)
I3RH01332020-01
3
2
I5RW0A330033-03
1
2
2
I5RW0A330034-01
