1J-12 Charging System:

Charging System Specifications

Battery
NOTE
The battery used in each vehicle is one of the following two types, depending on specification.
Rated capacity
Electrolyte
Battery
: 46B24R (40.6AH/5HR), 55B24R (42.5AH/5HR) 12V
Generator
Type
Rated voltage
Nominal output
Permissible max. speed
No-load speed
Regulated voltage
Exposed brush length
Permissible ambient temperature
Polarity
Rotation

Tightening Torque Specifications

Fastening part
Generator bracket bolt
Generator pivot bolt
Generator adjusting bolt
NOTE
The specified tightening torque is also described in the following.
"Generator Dismounting and Remounting"
"Generator Components"
Reference:
For the tightening torque of fastener not specified in this section, refer to "Fasteners Information in Section 0A".

Specifications

Battery type
AH/5HR, 12 Volts
L (US / lmp pt.)
46B24R
40.6
70 A type
12 V
70 A
18,000 r/min.
1020 r/min. (rpm)
14.2 – 14.8 V (Hi), 12.5 – 13.1 V (Lo)
Standard: 10.5 mm (0.41 in.)
Limit: 1.5 mm (0.05 in.)
–30 to 90 °C (–22 to 194 °F)
Negative ground
Clockwise viewed from pulley side
Tightening torque
N⋅m
kgf-m
25
2.5
50
5.0
Tighten 7.0
0.7
55B24R
2.8 (5.92 / 4.93)
lb-ft
18.0
36.0
by the specified
5.0
procedure.
S7RW0A1A07001
42.5
S7RW0A1A07002
