3.6.3 ONENAND DEVICE INTERRUPT HANDLING

The OneNAND interface provides two mechanisms to check the INT pin status of the OneNAND devices, namely:
1. Polling the INTD (INT Done) bits of the OneNAND Interface Status (ONENAND_IF_STATUS) register
2. Interrupt-driven checking.
The OneNAND controller requires that the system software should follow the correct operation sequence to check
the INT pin status of the OneNAND device as shown in
Note that the OneNAND interface detects only the rising edge of the INT pin. Therefore, set the INT Polarity
(INTpol) bit of the System Configuration 1 register (device address offset: 0x1E442) of the OneNAND device to 1.
illustrates the timing diagram of the INT pin of the OneNAND device and related SFR signals. The
Figure 3-8
is described below:
Figure 3-8
•
T1: New command (ex. load, program or erase) is written to the OneNAND device Command register
•
T2: OneNAND device INT pin rising edge occurs
•
T3: The INTD[x] bit of the OneNAND Interface Status (ONENAND_IF_STATUS) register is set to 1.
•
T4: OSINTD[x] (OneNAND Status INT Done) bit of the Interrupt Controller OneNAND Status
(INTC_ONENAND_STATUS) register is set to 1 because OMINTD[x] (OneNAND Mask INT Done) bit of the
Interrupt Controller OneNAND Mask (INTC_ONENAND_MASK) is deasserted to 0. Simultaneously,
ARM_IRQ pin is asserted to high to generate an interrupt to the system
•
T5: The system software (ex. ISR (Interrupt Service Routine)) writes 1 to the INTC[x] bit of the OneNAND
Interface Command (ONENAND_IF_CMD) register to clear the INTD[x] bit of the OneNAND Interface Status
(ONENAND_IF_STATUS) register.
•
T6: The INTD[x] bit of the OneNAND Interface Status (ONENAND_IF_STATUS) register is cleared to 0. T7:
The system software (ex. ISR (Interrupt Service Routine)) writes 1 to the OCINTD[x] bit (OneNAND Clear INT
Done) of the Interrupt Controller OneNAND Clear (INTC_ONENAND_CLR) register to clear the OSINTD[x]
(OneNAND Status INT Done) bit of the Interrupt Controller OneNAND Status (INTC_ONENAND_STATUS)
register.
•
T8: The OSINTD[x] (OneNAND Status INT Done) bit of the Interrupt Controller OneNAND Status
(INTC_ONENAND_STATUS) register is cleared to 0. Simultaneously, ARM_IRQ pin is deasserted to low.
and
Figure 3-6 Figure 3-7.
