CAN Registers
Table A-25. CAN Mailbox Registers (Cont'd)
Memory-Mapped
Address
0XFFC0 2DB0
0XFFC0 2DB4
0XFFC0 2DB8
0XFFC0 2DBC
0XFFC0 2DC0
0XFFC0 2DC4
0XFFC0 2DC8
0XFFC0 2DCC
0XFFC0 2DD0
0XFFC0 2DD4
0XFFC0 2DD8
0XFFC0 2DDC
0XFFC0 2DE0
0XFFC0 2DE4
0XFFC0 2DE8
0XFFC0 2DEC
0XFFC0 2DF0
0XFFC0 2DF4
0XFFC0 2DF8
0XFFC0 2DFC
0XFFC0 2E00
0XFFC0 2E04
0XFFC0 2E08
0XFFC0 2E0C
0XFFC0 2E10
A-36
Register Name
CAN_MB13_LENGTH
CAN_MB13_TIMESTAMP
CAN_MB13_ID0
CAN_MB13_ID1
CAN_MB14_DATA0
CAN_MB14_DATA1
CAN_MB14_DATA2
CAN_MB14_DATA3
CAN_MB14_LENGTH
CAN_MB14_TIMESTAMP
CAN_MB14_ID0
CAN_MB14_ID1
CAN_MB15_DATA0
CAN_MB15_DATA1
CAN_MB15_DATA2
CAN_MB15_DATA3
CAN_MB15_LENGTH
CAN_MB15_TIMESTAMP
CAN_MB15_ID0
CAN_MB15_ID1
CAN_MB16_DATA0
CAN_MB16_DATA1
CAN_MB16_DATA2
CAN_MB16_DATA3
CAN_MB16_LENGTH
ADSP-BF50x Blackfin Processor Hardware Reference
For individual bits, see this diagram:
Mailbox 13 Data Length Code Register
Mailbox 13 Time Stamp Value Register
Mailbox 13 Identifier Low Register
Mailbox 13 Identifier High Register
Mailbox 14 Data Word 0 [15:0] Register
Mailbox 14 Data Word 1 [31:16] Register
Mailbox 14 Data Word 2 [47:32] Register
Mailbox 14 Data Word 3 [63:48] Register
Mailbox 14 Data Length Code Register
Mailbox 14 Time Stamp Value Register
Mailbox 14 Identifier Low Register
Mailbox 14 Identifier High Register
Mailbox 15 Data Word 0 [15:0] Register
Mailbox 15 Data Word 1 [31:16] Register
Mailbox 15 Data Word 2 [47:32] Register
Mailbox 15 Data Word 3 [63:48] Register
Mailbox 15 Data Length Code Register
Mailbox 15 Time Stamp Value Register
Mailbox 15 Identifier Low Register
Mailbox 15 Identifier High Register
Mailbox 16 Data Word 0 [15:0] Register
Mailbox 16 Data Word 1 [31:16] Register
Mailbox 16 Data Word 2 [47:32] Register
Mailbox 16 Data Word 3 [63:48] Register
Mailbox 16 Data Length Code Register
