Table 21-21. RSI_STATUSCL Register
Bit Name
0 CMD_CRC_FAIL_STAT
1 DAT_CRC_FAIL_STAT
2 CMD_TIMEOUT_STAT
3 DAT_TIMEOUT_STAT
4 TX_UNDERRUN_STAT
5 RX_OVERRUN_STAT
6 CMD_RESP_END_STAT
7 CMD_SENT_STAT
8 DAT_END_STAT
9 START_BIT_ERR_STAT
ADSP-BF50x Blackfin Processor Hardware Reference
Removable Storage Interface
Function
Clear command response CRC fail
0 = No effect
1 = Clear CMD_CRC_FAIL
Clear data CRC failure
0 = No effect
1 = Clear DAT_CRC_FAIL
Clear command timeout
0 = No effect
1 = Clear CMD_TIMEOUT
Clear data timeout
0 = No effect
1 = Clear DAT_TIMEOUT
Clear transmit FIFO underrun
error
0 = No effect
1 = Clear TX_UNDERRUN
Clear receive FIFO overrun error
0 = No effect
1 = Clear RX_OVERRUN
Clear command response received
0 = No effect
1 = Clear CMD_RSEP_END
Clear command sent
0 = No effect
1 = Clear CMD_SENT
Clear end of data
0 = No effect
1 = Clear DAT_END
Clear start bit error
0 = No effect
1 = Clear START_BIT_ERR
Type Default
W1A 0
W1A 0
W1A 0
W1A 0
W1A 0
W1A 0
W1A 0
W1A 0
W1A 0
W1A 0
