Acm Missed Event Status (Acm_Ms) Register - Analog Devices ADSP-BF506F Hardware Reference Manual

ACM Registers

ACM Missed Event Status (ACM_MS) Register

The ACM Missed Event Status register indicates which enabled event has
been missed for a particular trigger cycle. When an
status indicates that event x was missed. This status generates an interrupt
if the corresponding bit in the
ACM Missed Event Status Register (ACM_MS)
EM15 (Event 15 Missed) W1C
0 - No event missed
1 - Event missed
EM14 (Event 14 Missed) W1C
0 - No event missed
1 - Event missed
EM13 (Event 13 Missed) W1C
0 - No event missed
1 - Event missed
EM12 (Event 12 Missed) W1C
0 - No event missed
1 - Event missed
EM11 (Event 11 Missed) W1C
0 - No event missed
1 - Event missed
EM10 (Event 10 Missed) W1C
0 - No event missed
1 - Event missed
EM9 (Event 9 Missed) W1C
0 - No event missed
1 - Event missed
EM8 (Event 8 Missed) W1C
0 - No event missed
1 - Event missed
Figure 22-20. ACM Missed Event Status (ACM_MS) Register
22-36
ACM_EMSK
15 14 13 12 11 10 9 8
0 0 0 0 0 0 0 0
ADSP-BF50x Blackfin Processor Hardware Reference
bit is set (=1), this
EMx
register is set.
7 6 5 4 3 2 1 0
0 0 0 0 0 0 0 0 Reset = 0x0000
EM0 (Event 0 Missed) W1C
0 - No event missed
1 - Event missed
EM1 (Event 1 Missed) W1C
0 - No event missed
1 - Event missed
EM2 (Event 2 Missed) W1C
0 - No event missed
1 - Event missed
EM3 (Event 3 Missed) W1C
0 - No event missed
1 - Event missed
EM4 (Event 4 Missed) W1C
0 - No event missed
1 - Event missed
EM5 (Event 5 Missed) W1C
0 - No event missed
1 - Event missed
EM6 (Event 6 Missed) W1C
0 - No event missed
1 - Event missed
EM7 (Event 7 Missed) W1C
0 - No event missed
1 - Event missed
