Analog Devices ADSP-BF506F Hardware Reference Manual page 1025

Table 21-11. RSI Module Registers (Cont'd)
Register Name
RSI_RESPONSE0
RSI_RESPONSE1
RSI_RESPONSE2
RSI_RESPONSE3
RSI_DATA_TIMER
RSI_DATA_LGTH
RSI_DATA_CONTROL
RSI_DATA_CNT
RSI_STATUS
RSI_STATUSCL
RSI_MASK0
RSI_MASK1
RSI_FIFO_CNT
RSI_CEATA_CONTROL RSI CE-ATA control register
RSI_FIFO
RSI_ESTAT
RSI_EMASK
RSI_CONFIG
ADSP-BF50x Blackfin Processor Hardware Reference
Removable Storage Interface
Function
RSI response registers
on page 21-60
RSI data timer register
on page 21-61
RSI data length register
on page 21-62
RSI data control register
on page 21-62
RSI data counter register
on page 21-64
RSI status register
on page 21-65
RSI status clear register
on page 21-68
RSI IRQ0 mask registers
on page 21-70
RSI FIFO counter register
on page 21-73
on page 21-74
RSI data FIFO register
on page 21-75
RSI exception status register
on page 21-75
RSI exception mask register
on page 21-77
RSI configuration register
on page 21-78
Address Type
0xFFC03804 R
0xFFC03808
0xFFC0381C
0xFFC03820
0xFFC03824 R/W
0xFFC03828 R/W
0xFFC0382C R/W
0xFFC03830 R
0xFFC03834 R
0xFFC03838 W1A
0xFFC0383C R/W
0xFFC03840
0xFFC03848 R
0xFFC0384C R/W1A/W 16-bit
0xFFC03880 R/W
0xFFC038C0 R/W1C
0xFFC038C4 R/W
0xFFC038C8 R/W
Access
32-bit
32-bit
16-bit
16-bit
16-bit
32-bit
16-bit
32-bit
16-bit
32-bit
16-bit
16-bit
16-bit
21-53
