CAN Registers
Table A-25. CAN Mailbox Registers (Cont'd)
Memory-Mapped
Address
0XFFC0 2E78
0XFFC0 2E7C
0XFFC0 2E80
0XFFC0 2E84
0XFFC0 2E88
0XFFC0 2E8C
0XFFC0 2E90
0XFFC0 2E94
0XFFC0 2E98
0XFFC0 2E9C
0XFFC0 2EA0
0XFFC0 2EA4
0XFFC0 2EA8
0XFFC0 2EAC
0XFFC0 2EB0
0XFFC0 2EB4
0XFFC0 2EB8
0XFFC0 2EBC
0XFFC0 2EC0
0XFFC0 2EC4
0XFFC0 2EC8
0XFFC0 2ECC
0XFFC0 2ED0
0XFFC0 2ED4
0XFFC0 2ED8
A-38
Register Name
CAN_MB19_ID0
CAN_MB19_ID1
CAN_MB20_DATA0
CAN_MB20_DATA1
CAN_MB20_DATA2
CAN_MB20_DATA3
CAN_MB20_LENGTH
CAN_MB20_TIMESTAMP
CAN_MB20_ID0
CAN_MB20_ID1
CAN_MB21_DATA0
CAN_MB21_DATA1
CAN_MB21_DATA2
CAN_MB21_DATA3
CAN_MB21_LENGTH
CAN_MB21_TIMESTAMP
CAN_MB21_ID0
CAN_MB21_ID1
CAN_MB22_DATA0
CAN_MB22_DATA1
CAN_MB22_DATA2
CAN_MB22_DATA3
CAN_MB22_LENGTH
CAN_MB22_TIMESTAMP
CAN_MB22_ID0
ADSP-BF50x Blackfin Processor Hardware Reference
For individual bits, see this diagram:
Mailbox 19 Identifier Low Register
Mailbox 19 Identifier High Register
Mailbox 20 Data Word 0 [15:0] Register
Mailbox 20 Data Word 1 [31:16] Register
Mailbox 20 Data Word 2 [47:32] Register
Mailbox 20 Data Word 3 [63:48] Register
Mailbox 20 Data Length Code Register
Mailbox 20 Time Stamp Value Register
Mailbox 20 Identifier Low Register
Mailbox 20 Identifier High Register
Mailbox 21 Data Word 0 [15:0] Register
Mailbox 21 Data Word 1 [31:16] Register
Mailbox 21 Data Word 2 [47:32] Register
Mailbox 21 Data Word 3 [63:48] Register
Mailbox 21 Data Length Code Register
Mailbox 21 Time Stamp Value Register
Mailbox 21 Identifier Low Register
Mailbox 21 Identifier High Register
Mailbox 22 Data Word 0 [15:0] Register
Mailbox 22 Data Word 1 [31:16] Register
Mailbox 22 Data Word 2 [47:32] Register
Mailbox 22 Data Word 3 [63:48] Register
Mailbox 22 Data Length Code Register
Mailbox 22 Time Stamp Value Register
Mailbox 22 Identifier Low Register
