H323-SGRP (323 Signaling Group)

H323-SGRP (323 Signaling Group)
MO Name (in
Alarm Log)
H323-SGRP
H323-SGRP
1. grp# is the signaling group number (1-166); the test sequence can be either short or
long.
The maintenance object H.323 Signaling Group (H323-SGRP) supports a
signaling channel (D-Channel) for H.323 Trunk connections. The MedPro TN802
circuit pack provides audio connectivity, working in concert with a C-LAN (TN799)
circuit pack which provides control signaling to support an H.323 connection.
The H.323 signaling group (H323-SGRP) is a Signaling channel that physically
resides on a C-LAN port (socket) and the IP network. Unlike ISDN D-channels,
the H.323 channel may actually come up and down on a call by call basis. The
H.323 channel is actually a TCP/IP signaling channel. Layers 1 and 2 of this
signaling channel are monitored by IP PING testing.
Error Log Entries and Test to Clear Values
Table 278. H323-SGRP Signaling Group Error Log Entries
Error Aux
Type Data
1
0 0 Any
1 (a) Any Ethernet Port Status Test
#1386
257 (b) Any H.323 SGRP PING Test
#1387
513(c) Any H.323 SGRP PING Test
#1387
770(d) Any
1025(e) Any MEDPRO Status Test
#1392
1281(f) Any MEDPRO Status Test
#1392
1794(g) MEDPRO Status Test
#1392
555-233-119
Alarm Level
MINOR test sig-group grp#
WARNING test sig-group grp#
Associated Test
Initial Command to
1
Run
Alarm On/Off
Level Board
Any
MINOR OFF
MINOR OFF
WARNING OFF
WARNING OFF
MINOR OFF
MINOR OFF
MINOR OFF
Continued on next page
Issue 5 October 2002
Full Name of MO
H323 Signaling Group
H323 Signaling Group
Test to Clear Value
test sig-group grp#
test sig-group grp#
test sig-group grp#
test sig-group grp#
test sig-group grp#
test sig-group grp#
1223
