Avaya DEFINITY Server CSI Maintenance Manual page 1460

Maintenance Objects
Table 388. TEST #572 Maintenance/Test Circuit Pack Query Test — Continued
Error Test
Code Result
2059 ABORT The Maintenance/Test Packet Bus port has reported a hardware failure.
2077 ABORT The Maintenance/Test Circuit Pack Query located more than one
Maintenance/Test Packet Bus port in the system.
2100 ABORT Maintenance could not allocate all of the necessary system resources to
perform this test.
2500 ABORT An internal operation failed; the test could not be completed.
XYZZ FAIL The Maintenance/Test Packet Bus port has detected faults on the Packet Bus.
The error code is encoded as follows:
1xxx The Maintenance/Test Packet Bus port has reconfigured the Packet Bus
around the faulty leads. This action occurs only in high or critical reliability
systems, and such a failure code should not appear in an R9CSI system.
2xxx The Maintenance/Test Packet Bus port is unable to correct all of the Packet
Bus faults it has detected.This action occurs only in high or critical reliability
systems, and such a failure code should not appear in an R9CSI system.
x0xx None of the Packet Bus faults are open faults.
x1xx At least some of the Packet Bus faults are open faults. Look for Error Type
2305 in the Error Log. The Aux Data value indicates the number of open leads.
xxZZ The last 2 digits of the error code indicate the total number of faulty Packet
Bus leads detected by the Maintenance/Test Packet Bus port.
PASS No faults have been detected on the Packet Bus by the Maintenance/Test
circuit pack. This indicates that the Packet Bus is operating correctly.
1460
Issue 5 October 2002
Description/ Recommendation
1. Re-enter the test command.
NOTE:
The software should not allow this to occur. This is an Internal system
error. Attempt the following work-around steps.
1. Remove all Maintenance/Test circuit packs from the system.
2. Insert one Maintenance/Test circuit pack (there should not be more than
one in a system).
3. Re-enter the test command.
1. Retry the command at 1-minute intervals a maximum of 5 times.
1. Refer to the "Packet Bus Fault Isolation Flowchart" section in Chapter 9 to
determine the cause of the failures.
Continued on next page
