MAPD-RES (TN802 reserve slot)

MAPD-RES (TN802 reserve slot)
MO Name (in
Alarm Log)
MAPD-RES
The TN802 MAPD (Multi-Application Platform for Avaya DEFINITY Server) circuit
pack connects to the switch through a single slot in the backplane, but the circuit
pack covers 3 slots. The TN802 uses one functional slot, plus 2 reserve slots to
the left of the functional slot. The reserve slots do not have any interaction with the
switch.
No tests are associated with this MO. Both test board and busy out board abort
when either is attempted on a reserved slot. An error message indicates that the
slot is a reserve slot associated with the circuit pack that the TN802 is emulating,
and the requested operation is not valid.
NOTE:
If you see error type 125 refer to maintenance object XXX-BD for repair
procedures.
555-233-119
Alarm Initial Command to
Level Run
MINOR NONE
Full Name of MO
TN802 MAPD reserve slot
Issue 5 October 2002
1373
