Ring-Gen (Analog Ring Generator) - Avaya DEFINITY Server CSI Maintenance Manual

Maintenance Objects

RING-GEN (Analog Ring Generator)

MO Name (in
Alarm Log)
RING-GEN
1. Where P is an appropriate port network number determined via the Port field from the
Alarm or Error Log.
All analog phones must be provided with a ringing voltage. The Analog Ring
Generator is part of the 650A AC Power Supply. A ringing voltage generator
failure means that no ringing can occur on analog phones; however, ringing on
digital and hybrid phones can still occur. The ringing voltage is monitored by the
Tone-Clock circuit pack.
Hardware Error Log Entries and Test to Clear
Values
Error Aux
Type Data
1
0 0 Any
1 Analog Ring Generator Query Test
(#118)
1. Run the Short Test Sequence first. If all tests pass, run the Long Test Sequence. Refer to the
appropriate test description and follow the recommended procedures.
1570
Issue 5 October 2002
Alarm
Level Initial Command to Run
MAJOR test environment P
Analog Ring Generator Error Log Entries
Associated Test
1
Analog Ring Generator
Alarm On/Off
Level Board
Any Any test environment PP
MAJOR ON test environment PP r 3
Full Name of MO
Test to Clear Value
