CLSFY-PT (Call Classifier Port)
System Technician-Demanded Tests: Descriptions
and Error Codes
Always investigate tests in the order presented in the following tables when
inspecting errors in the system. By clearing error codes associated with the Tone
Detection Verification Test, for example, you may also clear errors generated from
other tests in the testing sequence.
Table 151. System Technician-Demanded Tests: CLSFY-PT
Order of Investigation
Tone Detection Verification Test (#42)
Tone Detection Audit/Update Test (#43)
1. D = Destructive, ND = Non-destructive
Tone Detection Verification Test (#42)
This test checks out each port in both the touch-tone receiver mode and in the
R2-MFC tone detection/generation mode. During the first half of the test, the
touch-tone receiver mode is tested. In the second half of the test, each port is put
into the R2-MFC mode. During this portion of the test, each port's ability to
accurately detect and generate all forward and backward MFC tones is verified.
Table 152. TEST #42 Tone Detection Verification Test
Error Test
Code Result
none ABORT
1 ABORT
1001 ABORT
1002 ABORT
555-233-119
Description/ Recommendation
The system was not able to allocate all the resources needed for this test
OR there was an internal system error
The system could not allocate all the resources needed to test the tones.
The system was unable to put the Call Classifier port in the appropriate
mode to test it.
The system could not allocate time slots for the test connection. This
situation could occur when the system is heavily loaded. If the system is not
heavily loaded, test the TDM-BUS with test tdm [1|2]. Refer to the
TDM-BUS (TDM Bus) Maintenance documentation for details.
1. Retry the command at 1-minute intervals a maximum of 5 times.
Short Test Long Test
Sequence Sequence
X
X
Continued on next page
Issue 5 October 2002
1
D/ND
X ND
X ND
Continued on next page
