DIOD-TRK (DIOD Trunk)
Table 216. TEST #0 Dial Tone Test — Continued
Error Test
Code Result
1002 ABORT
1004 ABORT
1018 ABORT
1005 ABORT
2000 ABORT
FAIL
2002 FAIL
1009 PASS
PASS
555-233-119
Description/ Recommendation
The system could not allocate time slots for the test. The system may be
under heavy traffic conditions or it may have time slots out-of-service due to
TDM-BUS errors. Refer to TDM-BUS (TDM Bus) Maintenance
documentation to diagnose any active TDM-BUS errors.
1. If the system has no TDM-BUS errors and is not handling heavy traffic,
repeat test at 1-minute intervals a maximum of 5 times.
The port has been seized by a user for a valid call. Use the status trunk
command to determine when the port is available for testing.
1. Retry the command at one minute intervals a maximum of 5 times.
Test has been disabled via administration.
1. Verify that the
Maintenance Tests?
Form is set to n. To enable the test, issue the change trunk-group x
command where "x" equals the number of the trunk group to be tested.
Then change the entry in the
form to y.
Trunk has been administered as incoming-only; or DID trunk group type;
dial tone can only be obtained on outgoing trunks. This is a normal
condition.
Response to the test was not received within the allowable time period.
1. Retry the command at 1-minute intervals a maximum of 5 times.
Trunk was seized, but dial tone could not be detected.
1. Check for errors on TONE-BD or TONE-PT. Clear any errors found and
repeat test.
2. If error has still not cleared, refer problem to CO.
Seizure portion of test failed due to hardware problem. Fault is usually
caused by a disconnected trunk.
1. Check trunk wiring to ensure good connection; repeat test if wiring
correction made.
2. Locate another identical CO trunk and swap its wiring with one under
test. Repeat test on both trunks and determine if problem follows trunk
or remains at original port. If problem follows trunk, refer problem to
CO. If problem remains at port, replace circuit pack and repeat test.
Detected tone was not pure dial tone. No action required.
Trunk was seized, and dial tone was detected. User-reported troubles on
this port should be investigated by using other port tests and by examining
trunk or external wiring.
field on the Trunk Group
Maintenance Tests?
Continued on next page
