Avaya DEFINITY Server CSI Maintenance Manual page 1349

MAPD-BD (MAPD Interface Circuit Pack TN802)
5. Click on Details and configure the settings
6. Click on the new item icon and the laptop connects to the host
pcANYWHERE
8 7
Figure Notes:
1. To TN802 cabinet backplane
2. VGA monitor
3. USB (Universal Serial Bus)
4. Keyboard
Figure 40. TN802 external cable assembly
555-233-119
Table 333. Remote connection settings
Field
Speed
Parity
Flow Control
Started by
Ended by
®
application on the TN802 circuit pack.
6
(Table 333):
Value
38,400
None (default)
RTS/CTS
Carrier detect (DCD)
Carrier detect (DCD)
Continued on next page
5 4 3
5. Mouse
6. Ethernet
7. 25-pin modem connection
8. 25-pin COM2 connection
Issue 5 October 2002
1
2
cbdfocto AWF 122398
1349
