Avaya DEFINITY Server CSI Maintenance Manual page 1389

MEDPROPT (TN802/TN2302 MED PRO DSP PORT)
System Technician-Demanded Tests:
Descriptions and Error Codes
Investigate tests in the order they are presented in
codes associated with the DSP Capacity Query Test, for example, you may also
clear errors generated from the other test in the testing sequence.
Table 359. System Technician-Demanded Tests
Order of Investigation
DSP Capacity Query (#1382)
TDM NIC Looparound Test (#1380)
Port Status Test (#1407)
1. D = Destructive; ND = Nondestructive
DSP Capacity Query Test (#1382)
This test is non-destructive
If you have the TN802B
When using theTN802B, this test polls the circuit pack for the number of failed
DSPs. If all DSPs are functional, the test passes and the board is operating at
maximum capacity. If any DSPs have failed, the test fails and reports the number
of failed DSPs.
A failure of 3 or fewer DSPs does not result in an alarm. A failure of more than 3
and up to 8 DSPs results in a warning alarm. A failure of more than 8 DSPs
results in a minor alarm. In all cases, except when all DSPs fail, the MEDPROPT
continues to provide reduced capacity.
If you have the TN2302
When using the TN2302 this test polls the circuit pack for the state of health of a
specific DSP. If the DSP is bad an error will be logged and the board will be polled
again. If the circuit pack is still failing, the DSP will be taken out of service and a
MINOR alarm will be raised.
555-233-119
Table 359. By clearing error
Short Test Long Test
Sequence Sequence
X
X
X X
Issue 5 October 2002
1
D/ND
ND
ND
ND
1389
