Avaya DEFINITY Server CSI Maintenance Manual page 1572

Maintenance Objects
Analog Ring Generator Initialization Test (#117)
This test reports an error to the system software if the ringing voltage falls to low
(only if system software has made a request to the tone clock to monitor the
voltage). The Analog Ring Generator Initialization Test sends a request to the
active tone/clock.
Table 444. TEST #117 Analog Ring Generator Initialization Test
Error Test
Code Result
1 ABORT The system software is unable to determine the active tone/clock circuit pack,
1000 unable to allocated the resources necessary to run the test, or unable to send
1001 a down link message.
1003
1115
2012
2100
2000 ABORT Response to the request was not received within the allowable time period.
1005 ABORT The tone/clock is unable to read the analog ringing voltage level when the
tone/clock is in the Processor Interface slot. This test is not available for the
Processor Port Network in this configuration.
PASS The active Tone/Clock has successfully been enabled to monitor the ringing
voltage level.
Analog Ring Generator Query Test (#118)
This test requests the Active Tone-Clock circuit pack to check the ringing voltage.
The tone/clock circuit pack replies with PASS if the ringing voltage is adequate to
ring the analog phones. If not, the active tone/clock circuit pack replies with a
FAIL. The Analog Ring Generator Query Test then reports the result.
1572
Issue 5 October 2002
Description/ Recommendation
1. Wait for the green LED on the active tone/clock to go out; use the status
port-network command to determine the active Tone/Clock circuit pack.
2. Rerun the test. If the test aborts again, refer to TDM-CLK Maintenance
documentation.
1. Look for TDM-CLK errors and alarms. Resolve all other Tone/Clock
problems first.
2. Rerun the test.
Continued on next page
