External Device Alarm Test (#120)
The External Device Alarm Test requests the state of the External Device Alarm
from the Maintenance circuit pack and reports the results. The test has no effect
on the external device itself.
Table 265. TEST #120 External Device Alarm Test
Error Test
Code Result
1000 ABORT
2000 ABORT
2029 ABORT
2319
2320
2500
ANY FAIL
PASS
1186
Issue 5 October 2002
Description/ Recommendation
System resources required to run this test are not available.
1. Retry the command at 1-minute intervals a maximum of 5 times.
Response to the test request was not received within the allowable time
period.
1. Retry the command at 1-minute intervals a maximum of 5 times.
2. If the test continues to ABORT with error code 2000, check for system
powering problems with the A carrier. Look for and resolve all
AC-POWER alarms. Then, repeat the test.
3. If the test continues to ABORT with a 2000 error code, check for and
resolve all SYSAM errors. Then, repeat the test.
Internal system error
1. Retry the command at 1-minute intervals a maximum of 5 times.
The External Device Alarm has been activated by the external device.
1. Clear the major alarm on the external device, and rerun the test.
2. If the test still fails, then disconnect the External Device Alarms from
the Maintenance circuit pack and rerun the test.
3. If the test still fails, then there is a problem with the Maintenance circuit
pack that is reporting the alarm. This circuit pack should be replaced.
There are failures that can occur on Maintenance circuit pack's that will
not be detected by their respective maintenance, but which will cause
many environment tests to fail. If many environment tests are failing,
the suspect circuit pack should be replaced and the test rerun.
If there is a problem with the external device, but the Maintenance circuit
pack connected to the device reports no alarm, then the External Device
may not be properly reporting the problems or the External Device may not
be properly connected to the External Device.
Continued on next page
