DTMR-PT [Dual Tone Multifrequency
Port (TTR)]
MO Name (in Alarm
Alarm Log) Level
DTMR-PT MAJOR
DTMR-PT MINOR
DTMR-PT WARNING
1. Where P is the port network number (1 for PPN); C is the carrier designation (for example, A, B, or
C); SS is the address of the slot in the carrier where the circuit pack is located (for example, 01, 02,
etc.); and pp is the 2-digit port number (for example, 01).
The Dual Tone Multifrequency Receiver Port (DTMR), also known as the
Touch-Tone Receiver (TTR), resides on the Tone Detector circuit pack (TN748,
TN420) or the TN756 Tone-Clock circuit pack. There are four Dual Tone
Multifrequency Receiver (DTMR-PT) ports and two General Purpose Tone
Detector (GPTD-PT) ports on a Tone Detector circuit pack. The DTMR port is
used to detect touch-tone digits that are placed on the TDM bus. Examples of
touch-tone digits are digits 0 through 9, #, and *. The ability of the DTMR port to
detect touch-tone digits is essential for maintenance of other circuit packs (for
example, Tone-Clock circuit pack) and in placing a station-to-station call. Calls
originating from a hybrid station do not require a DTMR port.
The Dual Tone Multifrequency Receiver Port maintenance object defines a set of
tests to verify that the DTMF digits detection capability of the DTMR port is
functioning properly. For all Tone Detector circuit pack level errors (DETR-BD),
refer to the XXX-BD (Common Port Circuit Pack) Maintenance documentation.
1146
Issue 5 October 2002
Initial Command to
1
Run
test port PCSSpp sh
test port PCSSpp sh
release port PCSSpp
Full Name of MO
Dual Tone Multifrequency Receiver
Port (TTR)
Dual Tone Multifrequency Receiver
Port (TTR)
Dual Tone Multifrequency Receiver
Port (TTR)
555-233-119
