TDM Bus Clock Parameter Update Test (#151)
This test updates the following internal parameters on the Tone-Clock circuit pack:
Disable in-line duplication status messages.
Set the PPM threshold at 85 PPM for TN2182.
Enable PPM threshold switching
Set the number of slips to trigger loss of signal - currently 30 per 5
millisecond period
Enable the on-board synchronization switching algorithm (see above)
Enable holdover operation (TN2182 only).
This is not a test and will always pass without identifying or reporting any
Tone-Clock circuit pack errors
Table 493. TEST #151 TDM Bus Clock Parameter Update Test
Error Test
Code Result
ABORT
FAIL
PASS

TIE-BD (Tie Trunk Circuit Pack)

MO Name (in
Alarm Log)
TIE-BD
TIE-BD
1. Where P is the port network number (1); C is the carrier designation (for example, A, B, or C); and
SS is the address of the slot in the carrier where the circuit pack is located (for example, 01, 02, etc.).
Refer to ''XXX-BD (Common Port Circuit Pack)''
circuit pack level errors. See also
1676
Issue 5 October 2002
Description/ Recommendation
Internal System Error
Internal System Error
1. Retry the command at 1-minute intervals a maximum of 5 times.
The Tone-Clock circuit pack parameters have been successfully updated.
Alarm Level Initial Command to Run
MIN test board PCSS sh
WRN test board PCSS sh
1
Maintenance documentation for
''TIE-TRK (Tie Trunk)''.
Continued on next page
Full Name of MO
Tie Trunk Circuit Pack
Tie Trunk Circuit Pack
