RDIG-STA (Remote Digital Station)
Table 441. TEST #16 DIG-LINE Station Lamp Updates Test — Continued
Error Test
Code Result Description/ Recommendation
FAIL Internal system error
PASS The message to light all of the station lamps was sent successfully to
the port.
Digital Station Audits Test (#17)
This is a series of six tests that are classified as audits. The SPE sends messages
to the on-board microprocessor to perform the tests. These audits run only if the
station is in-service.
Switchhook Inquiry Test
to the circuit pack's records. This inquiry is sent all the way to the voice
terminal.
Bad Scan Inquiry Test
is generated based on certain events relating to the link conditions. This
can be an indication of communications problems between the Processor
and Digital Port circuit pack.
EPF/PTC Inquiry Test
sent uplink. Possible conditions are: EPF-on-ok, EPF-off.
ID Request Test
station sends its configuration information and health information back.
This information is checked and a pass/fail result is provided.
Ringer Update
to the processor records.
DTMF Administration Update
refresh the default value that causes the station to send touch- tones only
in the primary information channel. This value is set initially when the
station is put in-service and every time the station's state changes from
other states to in-service.
555-233-119
1. Retry the command at 1-minute intervals a maximum of 5 times.
1. Observe the station lamps being lit when running the test. If all
lamps do not light, the other Digital Line test results may indicate
related problems that do not allow the lamps to light.
2. Investigate by using other Digital Line port tests, and by
examining the station, wiring, and connections.
—
—
A message is sent uplink containing a count that
—
The status of the Electronic Power Feed (EPF) is
—
A request is made to the station for its status. The
—
This updates the digital telephone ringer state according
Continued on next page
This is an update of the SPE records according
—
This is a message to the digital station to
