Avaya DEFINITY Server CSI Maintenance Manual page 1043

DIG-LINE (Digital Line)
Table 207. TEST #16 DIG-LINE Station Lamp Updates Test — Continued
Error Test
Code Result
PASS
Digital Station Audits Test (#17)
This is a series of six tests which are classified as audits. The SPE sends
messages to the on-board microprocessor to perform the following tests. These
audits run only if the station is in-service.
Switchhook Inquiry Test
to the circuit pack's records. This inquiry is sent all the way to the voice
terminal.
Bad Scan Inquiry Test
that is generated due to certain events relating to the link conditions. This
can be an indication of communications problems between the Processor
and Digital Port circuit pack.
EPF/PTC Inquiry Test
the Electronic Power Feed (EPF) is sent uplink. Possible conditions are:
EPF-on-ok, EPF-off, and EPF-no-load. For TN754 vintage 14 or later,
TN754B or TN2136, TN2181, TN2224, the status of the Positive
Temperature Coefficient (PTC) is sent uplink. Possible conditions are:
PTC-on-ok, PTC-off, and PTC-no-load.
ID Request Test
station sends its configuration information and health information back.
This information is checked and a pass/fail result is provided.
Ringer Update Test
according to the processor records.
DTMF Administration Update Test
station to refresh the default value which causes the station to send
touch-tones only in the primary information channel. This value is set
initially when the station is put in-service and every time the station's state
changes from other states to in-service.
555-233-119
Description/ Recommendation
The message to light all of the station lamps was sent successfully to the
port.
1. Observe the station lamps being lit when running the test. If all lamps
do not light successfully, the other Digital Line test results may indicate
related problems that will not allow the lamps to light.
2. Investigate by using other Digital Line port tests, and by examining the
station, wiring, and connections.
—
This is an update of the SPE records according
—
A message is sent uplink which contains a count
—
For a TN754 vintage 13 or earlier, the status of
—
A request is made to the station for its status. The
—
This updates the digital telephone ringer state
Continued on next page
—
This is a message to the digital
Issue 5 October 2002
