TONE-BD (Tone-Clock Circuit Pack)
Table 510. System Technician-Demanded Tests: TONE-BD (TN2182 only)
Order of Investigation
SAKI Reset Test (#53) (a)

Clock Health Inquiry Test (#46)

Control Channel Loop Around Test (#52) (a)
Tone Generator Crosstalk Test (#90) (b)
Tone Generator Transmission Test (#40) (b)
Tone Generator Audit/Update (#41) (b)
TDM Bus Clock Circuit Status Inquiry Test (#148) (c)
TDM Bus Clock Slip Inquiry (#149) (c)
TDM Bus Clock PPM Inquiry Test (#150) (c)
TDM Bus Clock Parameter Update Test (#151) (c)
Board Type Check Test (#574) (c)
Standby Reference Health Check Test (#651) (c,)
1. D = Destructive, ND = Non-destructive
Notes:
a. Refer to XXX-BD for descriptions of these tests.
b. Refer to TONE-PT for descriptions of these tests.
c. Refer to TDM-CLK for descriptions of these tests.
Clock Health Inquiry Test (#46)
This inquiry reads special data stored in memory to determine if this Tone-Clock
circuit pack had a loss of any of three clock types:
SYSCLK
SYSFM
SYSDCLK
If this data indicates this Tone-Clock circuit pack had a loss of any of these clocks,
the inquiry reports FAIL. In addition, if TDM-CLK error 1 is at threshold, this test
will FAIL. TDM-CLK error 1 indicates a suspect clock is at the edge of its specified
frequency. If the circuit pack did not have a loss of clock or TDM-CLK error 1 at
threshold, the inquiry reports PASS.
555-233-119
Short Test Long Test
Sequence Sequence
X
X X
X X
X
X X
X X
X X
X X
X X
X X
X X
X
Issue 5 October 2002
1
D/ND
1727
