TONE-BD (Tone-Clock Circuit Pack)
Notes:
a. Error Type 1
functioning or it was physically removed from the system.
If the circuit pack is not present in the system, insert a circuit pack in the
slot indicated by the error to resolve the error.
If the circuit pack is present in the system, it is faulty and must be replaced.
See the preceding section,
b. Error Type 18
unavailable via the busyout tone-clock PC command. This error applies
only to High or Critical Reliability systems (an active Tone-Clock may not
be busied out). To resolve this error, execute release tone-clock PC.
c. Error Type 23
physically installed. Installing the circuit pack will resolve the alarm.
d. Error Type 125
circuit pack is logically administered. To resolve this problem, either
remove the wrong circuit pack and insert the logically administered circuit
pack OR use the change circuit-pack command to readminister this slot
to match the circuit pack inserted.
e. Error Type 126
log entry booted up without a Tone-Clock circuit pack, or with a one that
cannot communicate at all with the system. The error is logged five minutes
after the port network is restarted. If no circuit pack is present, install one of
the proper code. If there is a circuit pack present, replace it. See the
preceding section,
replacement does not solve the problem, follow normal escalation
procedures.
f. Error Type 257
with this circuit pack. This error is not service-affecting and no action is
required.
g. Error Type 513
Replace the circuit pack using the procedure described in preceding
section,
h. Error Type 769
circuit pack.
i. Error Type 1025
required.
555-233-119
This error indicates the circuit pack totally stopped
NOTE:
The alarm is logged approximately 11 minutes after the circuit pack is
removed/SAKI Sanity Test (#53) fails.
''How to Replace a Tone-Clock Circuit
The indicated Tone-Clock circuit pack has been made
The circuit pack has been logically administered but not
A wrong circuit pack is inserted in the slot where this
The port network specified in the PORT field of the error
''How to Replace a Tone-Clock Circuit
his error indicates transient communication problems
This circuit pack has an on-board hardware failure.
''How to Replace a Tone-Clock Circuit
This error can be ignored, but look for other errors on this
This error is not service-affecting and no action is
Pack''.
Pack''. If
Pack''.
