MAPD-BD (MAPD Interface Circuit Pack TN802)
Faceplate
Figure 39 shows the TN802 faceplate.
Figure Notes:
1. LCD display (see
1348)
2. Reset button (recessed)
3. Red board status LED
Figure 39. TN802 faceplate
555-233-119
2
4
5
fpdfmapd KLC 030899
Table 332 on page 4. PCMCIA card slot
5. Yellow PCMCIA disk-in-use LED
1
3
