DATA-CHL (Data Channel)
Data Channel Reset Test (#107)
This test is destructive.
This test resets the entire data communications interface provided by the four
DATA-CHLs. All existing connections over the DATA-CHLs are dropped.
Table 173. TEST #107 Data Channel Reset Test
Error Test
Code Result
1000 ABORT
2100 ABORT
ABORT
10704 ABORT
Any FAIL
PASS
Data Channel Dual Port RAM Test (#108)
This test is destructive.
This is a coordinated test of the dual port RAM that is shared between the
hardware and software. Control messages and data are passed through this dual
port RAM to establish and tear down connections over the DATA-CHLs. This test
requests each side to read and write the dual port RAM, first one at a time and
then simultaneously in alternate locations.
This test prevents any control stimuli from being received from or sent to the TDM
Bus control channel preventing the establishment of new connections over the
DATA-CHLs. However, existing connections are not (and cannot) be dropped.
555-233-119
Description/Recommendation
System resources required to run this test are not available.
1. Try the command at 1-minute intervals a maximum of 5 times.
System resources required for this test are unavailable.
An ABORT has one of two different meanings:
1. System resources required to run this test are not available.
2. Internal system error
Internal system error
1. Try the command at 1-minute intervals a maximum of 5 times.
The circuit pack failed to reset.
1. Execute the command again.
2. If the problem persists, replace the Processor circuit pack.
After the Processor circuit pack has been replaced, its Time-of-Day clock
must be set using the set time command.
The circuit pack initializes correctly.
Continued on next page
