Avaya DEFINITY Server CSI Maintenance Manual page 755

ATM-SGRP (ATM Signaling Group)
Table 85. TEST #647 Layer 2 Status Query Test
Error Test
Code Result
1132 ABORT Internal system error. The port location for the D-channel is not known. This
condition should not be possible since an administered ATM circuit pack
must be specified when a Signaling Group is administered:
1134 ABORT Internal system error. The associated ATM circuit pack is not administered.
This condition should not be possible, since an administered ATM circuit
pack must be specified when administering a Signaling Group.
2500 ABORT Internal system error
1 FAIL Layer 2 of the signaling channel is down
3 FAIL The D-Channel is down.
PASS The Primary Signaling Channel is up.
555-233-119
Description/Recommendation
1. Retry the command at one minute intervals a maximum of five times.
1. Retry the command at one minute intervals a maximum of three times.
1. Retry the command at one minute intervals a maximum of five times.
1. Examine the results of the Signaling Test (#636) and follow
recommendations provided there.
2. If Test #636 (Primary Signaling Link Hardware Check) passes, the Layer
2 Query test may still fail if the Signaling Channel at the far end has not
been administered correctly or if the Signaling Channel has been busied
out.
3. Verify that the Signaling Channel (D-channel) at the far end has been
administered correctly.
4. Verify that the ATM-DCH port used for the D-channel has not been
busied out at the far end.
1. Examine the results of the Primary Signaling Link Hardware Check
(#636) and follow recommendations provided there.
2. If Test #636 (Primary Signaling Link Hardware Check) passes, the Layer
2 Query test may still fail if the Signaling Channel at the far end has not
been administered correctly or if the Signaling Channel has been busied
out.
3. Verify that the Signaling Channel (D-channel) at the far end has been
administered correctly.
4. Verify that the ATM-DCH port used for the Primary and Secondary
D-channels has not been busied out at the far end.
Continued on next page
