O c t e l ® 1 0 0
M e s s a g i n g S e r v e r
Comdial
DXP
There are two other ways
to attach the Comdial DXP.
See paragraph 3.0
Communications between the
Comdial DXP and the O100 are
via DTMF Inband Signaling.
Supported Voice Processing
Module
Configuration Note 7042
Comdial DXP*
Revised 06/21/01
D
S
T
Digital Ports
Voice Board(s)
1.0
METHOD OF INTEGRATION
Inband. Call forward to personal greeting is achieved via DTMF signals
passed from the Comdial DXP to the Octel 100, hereafter identified by
(O100). Message waiting indicators are set and canceled by dialing a
feature access code followed by the extension number. A hook flash
followed by the extension transfers outside callers to the operator (internal
transfers are not possible).
1.1 SUPPORTED VOICE PROCESSING MODULE
The Octel 100 is a Year 2000 (Y2K) compliant, PC based, enhanced voice
messaging product release intended to replace the OPC, Signature
Performer, CEO, CP, and CP+ product lines. For installed systems that
Disclaimer: Configuration Notes are designed to be a general guide reflecting AVAYA Inc.'s experience
configuring its systems. These notes cannot anticipate every configuration possibility given the inherent
variations in all hardware and software products. Please understand that you may experience a problem
not detailed in a Configuration Note. If so, please notify the TAC/TSO at (408) 922-1822 and if
appropriate we will include it in our next revision. AVAYA Inc. accepts no responsibility for errors or
ATI
ATI
ATI
Personal Computer
omissions contained herein.
ATI
One ATI
per port
Advertisement
Related Manuals for Avaya Comdial DXP 7042
Summary of Contents for Avaya Comdial DXP 7042
- Page 1 Please understand that you may experience a problem not detailed in a Configuration Note. If so, please notify the TAC/TSO at (408) 922-1822 and if appropriate we will include it in our next revision. AVAYA Inc. accepts no responsibility for errors or omissions contained herein.
- Page 2 Industry Standard Station Cards can be found in Comdial's IMI-89- 078. The information contained in this document is provided by AVAYA Inc. to serve as a guide. See the disclaimer on page 1 Avaya Inc. PROPRIETARY. Use pursuant to Company instructions.
- Page 3 External Callers Only, See Section 7.1 Direct Call Limitations, See Section 7.4 The information contained in this document is provided by AVAYA Inc. to serve as a guide. See the disclaimer on page 1 Avaya Inc. PROPRIETARY. Use pursuant to Company instructions.
- Page 4 Transfer on Busy and Immediate Transfer. Both of these should be disabled. Disable Automatic Transfer on Busy as follows: The information contained in this document is provided by AVAYA Inc. to serve as a guide. See the disclaimer on page 1...
- Page 5 Vtree that answers calls according to how you set the Vtree up for that line. Program the ExecuMail ID as follows: The information contained in this document is provided by AVAYA Inc. to serve as a guide. See the disclaimer on page 1 Avaya Inc. PROPRIETARY. Use pursuant to Company instructions.
-
Page 6: Configuring Call Forward
1. Press INTERCOM and listen for dial tone. 2. Dial *52. The information contained in this document is provided by AVAYA Inc. to serve as a guide. See the disclaimer on page 1 Avaya Inc. PROPRIETARY. Use pursuant to Company instructions. - Page 7 The Integrator inserts the following codes. Adjust to match site requirements. above The information contained in this document is provided by AVAYA Inc. to serve as a guide. See the disclaimer on page 1 Avaya Inc. PROPRIETARY. Use pursuant to Company instructions.
- Page 8 Call Screening FaxMail Direct Call (for message retrieval) Unsupervised CO Lines The information contained in this document is provided by AVAYA Inc. to serve as a guide. See the disclaimer on page 1 Avaya Inc. PROPRIETARY. Use pursuant to Company instructions.
- Page 9 The O100 may experience delays in disconnecting if using unsupervised trunks. The information contained in this document is provided by AVAYA Inc. to serve as a guide. See the disclaimer on page 1 Avaya Inc. PROPRIETARY. Use pursuant to Company instructions.
- Page 10 This will alleviate the perception that the called subscriber is losing calls. ©1994-2001 Avaya Inc. All rights reserved. All trademarks identified by the ®, SM and TM are registered trademarks, servicemarks or trademarks respectively. All other trademarks are properties of their respective owners. The above information is based on knowledge available at the time of publication and is subject to change without notice.
