DAT-LINE (Data Line)
Conference Circuit Test (#7)
The Conference Circuit Test verifies that the NPE channel for the port being
tested can correctly perform the conferencing function. The NPE is instructed to
listen to several different tones and conference the tones together. The resulting
signal is then measured by a Tone Detector port. If the level of the tone is within a
certain range, the test passes.
Table 181. TEST #7 Conference Circuit Test
Error Test
Code Result
ABORT
1000 ABORT
1004 ABORT
1020 ABORT
2000 ABORT
2100 ABORT
Any FAIL
PASS
555-233-119
Description/Recommendation
Could not allocate the necessary system resources to run this test.
1. Retry the command at 1-minute intervals a maximum of 5 times.
System resources required to run this test are not available. The port may
be in use on a valid call. Use status data-module to determine when the
port is available for testing.
The port has been seized by a user for a valid call. Use status data-module
to determine when the port is available for testing.
1. Retry the command at 1-minute intervals a maximum of 5 times.
The test did not run due to an already existing error on this port (Error Type
769).
1. Refer to the procedure for Error Type 769. If Error Type 769 still occurs
on this port, replace the circuit pack.
Response to the test request was not received within the allowable time
period.
Could not allocate the necessary system resources to run this test.
1. Retry the command at 1-minute intervals a maximum of 5 times.
The conference circuit test failed (possible off-board problem).
1. Busyout and release the port (data line), and then retest.
2. Replace the circuit pack if the test continues to fail.
The port can correctly conference multiple connections. User-reported
troubles on this port should be investigated using other port tests, examining
the ADU, external wiring, and customer equipment.
Continued on next page
