DTMR-PT [Dual Tone Multifrequency Port (TTR)]
Hardware Error Log Entries and Test to Clear
Values
Table 245. Dual Tone Multifrequency Receiver Port (TTR) Error Log Entries
Error Aux
Type Data
1
0 0 Any
1(b) 17664 Tone Detector
Audit/Update Test
(#43)
18 0 busyout port PCSSpp
130(d) None
257(c) 17666 Tone Detector
Audit/Update Test
(#43)
513 Any Tone Detection
Verification Test (#42)
1. Run the Short Test Sequence first. If all tests pass, run the Long Test Sequence. Refer to the
appropriate test description and follow the recommended procedures.
Notes:
a. There are two possible alarm levels for this error: Major alarm and Minor
alarm. A Major alarm is raised if the total number of DTMR ports currently
in service is less than or equal to one half of the administered threshold
number. Otherwise, a Minor alarm is raised. In either case, run the Short
Test Sequence against the DTMR port and follow the error code
procedures for the individual tests.
The threshold number of DTMR ports for service is administered using the
change system-parameters maintenance command.
b. This error indicates the DTMR port is having problems detecting touch-tone
digits. If this error is being constantly logged, then the Tone Detector circuit
pack containing the defective DTMR port should be replaced.
c. The DTMR port lost its translation. Testing the DTMR port is sufficient to
reload its translation. If testing the DTMR port does not clear the error, then
the Tone Detector circuit pack containing the defective DTMR port should
be replaced.
d. This error type indicates that the circuit pack has been removed or has
been insane for at least 11 minutes. To clear the error, reinsert or replace
the circuit pack.
555-233-119
Associated Test
Any
MAJOR/
MINOR (a)
WARNING
WARNING
MAJOR/
MINOR (a)
MAJOR/
MINOR (a)
Alarm On/Off
Level Board
Any test port PCSSpp sh r 1
ON test port PCSSpp r 2
ON release port PCSSpp
ON test port PCSSpp sh r 2
ON test port PCSSpp r 3
ON test port PCSSpp r 3
