ETR-PT (Enhanced Tone Receiver Port)
Table 262. TEST #42 Tone Detection Verification Test — Continued
Error Test
Code Result
2100 ABORT
1-122 FAIL
102 FAIL
130 FAIL
PASS
555-233-119
Description/ Recommendation
Could not allocate the necessary system resources to run this test.
1. Retry the command at 1-minute intervals a maximum of 5 times.
DTMF digits were not detected correctly.
1. Run the short test sequence via the test port PCSSpp sh r 1
command.
2. If the problem persists, the system is still operating properly but
capacity will be reduced. To restore performance to normal, replace the
circuit pack containing the defective ETR-PT (Enhanced Tone Receiver
Port). Follow the procedures described in the TONE-BD section for
replacing a tone/clock circuit pack.
2225 Hz Modem Answer Tone was not detected correctly. This will impact
call-classification operation.
1. Run the short test sequence via the test port PCSSpp sh r 1
command.
2. If the problem persists, the system can still operate properly but
capacity will be reduced. In order to restore performance to normal,
replace the circuit pack containing the defective port. Follow the
procedures described in the TONE-BD section for replacing a
tone/clock circuit pack.
Forward or Backward MFC signals were not correctly generated or
detected. This will impact MFC calls.
1. Run the short test sequence via the test port PCSSpp sh r 1
command.
2. If the problem persists, the system can still operate properly but
capacity will be reduced. In order to restore performance to normal,
replace the TN2182 circuit pack containing the defective ETR-PT.
Follow the procedures described in the TONE-BD section for replacing
a tone/clock circuit pack.
Tone Detection Verification is successful. The ETR Port is able to
detect/generate all necessary tones.
Continued on next page
