DTMR-PT [Dual Tone Multifrequency Port (TTR)]
Table 246. TEST #42 Tone Detection Verification Test — Continued
Error Test
Code Result
1003 ABORT
2000 ABORT
2100 ABORT
2006 ABORT
1-3 FAIL
PASS
555-233-119
Description/ Recommendation
The system could not allocate a Tone Generator for the test connection.
This could happen when the system is heavily loaded or there is not a
Tone-Clock circuit pack in the port network when this test is being
executed.
1. Make sure there is a Tone-Clock circuit pack in the same port network.
2. If a Tone-Clock circuit pack is missing, install one in the same port
network.
3. Allow about 1 minute for the Tone-Clock maintenance to run on the
newly inserted Tone-Clock circuit pack.
4. Retry the command at 1-minute intervals a maximum of 5 times.
Response to the test request was not received within the allowable time
period.
Could not allocate the necessary system resources to run this test.
1. Retry the command at 1-minute intervals a maximum of 5 times.
DTMF detection failed. This could be caused by the administered
companding mode of the system not matching that of the Tone Detector
circuit pack.
1. Make sure that companding mode of the system matches that of the
Tone Detector.
DTMF digits were not correctly detected.
1. Run the Short Test Sequence: test port PCSSpp sh r 1.
2. If the problem persists, the system is still operating properly but system
capacity will be reduced. In order to restore the system performance to
normal, replace the Tone Detector circuit pack containing the defective
DTMR port.
The DTMR port is able to detect all the touch-tone digits.
Continued on next page
