PE-BCHL (PRI Endpoint Port)
Multiple PRI Endpoints on a one line-side facility are separate and distinct within
the facility. Non-overlapping contiguous sets of B-channels are associated with
each PRI Endpoint, and the endpoint equipment is expected to initiate calls within
these boundaries.
The endpoint application equipment must be able to:
use standard ISDN-PRI signaling
adhere to the PRI Endpoint boundaries as administered on Avaya
DEFINITY Server when initiating calls
handle incoming calls appropriately based on the PRI Endpoint
Signaling and B-channel States
These ports use a separate channel for signaling (for example, for call setup).
This mode of operation is known as out-of-band signaling. The separate signaling
channel is called a D-channel in ISDN terminology, and it carries all the call
control signaling messages for the PRI Endpoint Port B-channels. The D-channel
for these B-channels is an ISDN-PRI Signaling Link Port (ISDN-LNK). The
signaling protocol used on the ISDN-PRI Signaling Link Port D-channel is defined
by one of the four selectable ISDN-PRI Specifications: AT&T, CCITT, ECMA, and
ANSI.
The ISDN-PRI Specification defines the possible SERVICE STATES for a
B-channel. The service state is negotiated with the far-end terminal adapter, and it
changes over time. Also, the service state may have a far-end or near-end
component, and it is initialized to the Out-Of-Service/Far-End state. An attempt is
made to negotiate the service state to In-Service.
NOTE:
The service state of a particular PRI Endpoint Port B-channel can be
displayed by issuing the status pri-endpoint <extension> system
technician command.
If a call is present, the ISDN-PRI Specification defines the permissible CALL
STATES as well. There are tests in the short and long test sequences for PRI
Endpoint Port that are designed to audit these states and to ensure agreement
between both ends of the PRI wideband connection.
