Avaya DEFINITY Server CSI Maintenance Manual page 1348

Maintenance Objects
Table 332 lists the TN802 LCD messages that you might see if installing or
servicing an IP Trunk.
Table 332. TN802 LCD messages for IP trunks
Display
PC BOOT
IP TRK #
IML DWN #
MSHUT # where both MSHUT
and # are blinking
MSHUT #, where # is blinking
Support for laptop PCs
Field technicians can access the TN802 circuit pack through:
1. ''pcANYWHERE® client software''
2. ''Directly-connected keyboard, monitor, and mouse''
E ®
client software
pcANYWHER
1. Attach a male-to-male serial cable and a NULL modem connector (if not
built into the cable you use) to the COM2 connector (Note 8 in
page
2. Launch the pcANYWHERE
3. Click on Add Remote Control Item.
4. In the Properties window, choose the communication port to which you
connected the cable in Step 1.
1348
Issue 5 October 2002
Explanation
The TN802 MAPD PC is booting up.
IP Trunk application is running (# character blinks)
Internal error on the IP Trunk. System shuts down
and sends and error message to the board.
The system is in the process of shutting down due to
a front panel button press. DO NOT attempt to
remove board.
The system has shut down gracefully.
1349) Attach the other end to the serial port of your laptop.
®
application.
Continued on next page
Figure 40 on
