Avaya DEFINITY Server CSI Maintenance Manual page 775

ATM-TRK (Circuit Emulation Service Circuit Pack)
ATM Board Reset (#1256)
This test is destructive.
This test checks the sanity of the angel processor using the Sanity and Control
Interface (SAKI) test (Common Port Board test #53). It resets the circuit pack if the
SAKI test fails and runs the test again.The ATM Board Reset test passes if SAKI
can successfully reset and retest the board.
Before running the SAKI test:
Move synchronization off the ATM-TRK circuit pack
Busyout the ATM-TRK circuit pack
The test aborts if the ATM-TRK circuit pack is supplying synchronization.
Table 99. ATM Board Reset (#1256)
Error Test
Code Result
1005 ABORT Wrong circuit pack configuration to run this test. The ATM CES Trunk
Interface circuit pack provides timing for the system and cannot be reset
without major system disruptions.
Set synchronization to another ATM CES trunk circuit pack or to the
Tone-Clock circuit pack and test again.
1015 ABORT Test cannot be run because the ATM-TRK circuit pack has not been busied
out.
Busyout out the circuit pack (busyout board UUCSS).
Repeat the test (test board UUCSS long).
None ABORT Could not allocate the required system resources
Retry the command up to 5 times at 1-minute intervals.
If the test continues to abort escalate the problem.
2000 ABORT Sanity test timed out.
Wait 5 minutes, and see if ATM-TRK circuit pack is visible to the system by
running list configuration all.
If the ATM-TRK circuit pack is visible (list configuration all), run the test
again, and escalate if the problem recurs.
If the ATM-TRK circuit pack is not visible to the system (list configuration
all), re-seat the ATM-TRK circuit pack, and retest.
If the ATM-TRK circuit pack is still not recognized by the system, replace the
board.
555-233-119
Description/Recommendation
Issue 5 October 2002
Continued on next page
775
