bgp: Specifies the BGP protocol.
isis: Specifies the IS-IS protocol.
ospf: Specifies the OSPF protocol.
rip: Specifies the RIP protocol.
statitc: Specifies a static route.
process-id: Process number of the unicast routing protocol, in the range of 1 to 65535. This argument
must be provided if IS-IS, OSPF or RIP is the specified unicast routing protocol.
policy-name: Name of the multicast route match rule, a case sensitive string of up to 19 characters
without any space.
rpf-nbr-address: Specifies an RPF neighbor by the IP address.
interface-type interface-number: Specifies an interface by its type and number.
preference: Route preference, in the range of 1 to 255 and defaulting to 1.
order-number: Match order for routes on the same segment, in the range of 1 to 100.
Description
Use the ip rpf-route-static command to configure a multicast static route.
Use the undo ip rpf-route-static command to delete a multicast static route from the multicast static
routing table.
By default, no multicast static route is configured.
Note that:
If vpn-instance is not specified, this configuration takes effect only on the public instance.
The arguments source-address { mask | mask-length }, protocol and policy-name are critical
elements in multicast static route configuration. The variation of any of these three arguments
results in a different configuration.
In the configuration, you can use the display multicast routing-table static command to check
whether the multicast static route information contains this configuration. If you find a match,
modify the corresponding fields without changing the configuration sequence; otherwise, add a
multicast static route.
When configuring a multicast static route, you can specify an RPF neighbor only by providing its IP
address (rpf-nbr-address) rather than its interface type and number (interface-type
interface-number) if the interface type of the RPF neighbor is Ethernet, Layer 3 aggregate,
Loopback, RPR, or VLAN-interface.
Because outgoing interface iteration may fail or the specified interface may be in the down state,
the multicast static route configured with this command may fail to take effect. Therefore, we
recommend that you use the display multicast routing-table static command after you configure
a multicast static route to check whether the route has been successfully configured or whether the
route has taken effect.
Related commands: display multicast routing-table static.
Examples
# Configure a multicast static route to the multicast source 10.1.1.1/24, specifying a router with the IP
address of 192.168.1.23 as its RPF neighbor.
<Sysname> system-view
[Sysname] ip rpf-route-static 10.1.1.1 24 192.168.1.23
