1: Vlan-interface2
Protocol: pim-sm, UpTime: 02:54:43, Expires: 00:02:47
Table 1-9 display pim routing-table command output description
VPN-Instance: public net
Total 0 (*, G) entry; 1 (S, G) entry
(172.168.0.2, 227.0.0.1)
Protocol
Flag
Uptime
Upstream interface
Upstream neighbor
RPF prime neighbor
Downstream interface(s) information

display pim rp-info

Syntax
display pim [ all-instance | vpn-instance vpn-instance-name ] rp-info [ group-address ]
View
Any view
Default Level
1: Monitor level
Parameters
all-instance: Specifies all instances.
vpn-instance vpn-instance-name: Specifies a VPN instance. A VPN instance name is a case sensitive
string of up to 31 characters and must not contain any space.
group-address: Address of the multicast group of which the RP information is to be displayed, in the
range of 224.0.1.0 to 239.255.255.255. If you do not provide a group address, this command will display
the RP information corresponding to all multicast groups.
Field Description
Public instance
Number of (S,G) and (*, G) entries in the PIM routing table
An (S, G) entry in the PIM routing table
PIM mode, PIM-SM or PIM-DM
Flag of the (S, G) or (*, G) entry in the PIM routing table
Length of time for which the (S, G) or (*, G) entry has been
existing
Upstream (incoming) interface of the (S, G) or (*, G) entry
Upstream neighbor of the (S, G) or (*, G) entry
RPF neighbor of the (S, G) or (*, G) entry
For a (*, G) entry, if this router is the RP, the RPF
neighbor of this (*, G) entry is NULL.
For a (S, G) entry, if this router directly connects to the
multicast source, the RPF neighbor of this (S, G) entry
is NULL.
Information of the downstream interface(s), including:
Number of downstream interfaces
Downstream interface name
Protocol type on the downstream interface(s)
Uptime of the downstream interface(s)
Expiry time of the downstream interface(s)
