3Com S7906E Command Reference Manual page 1589

Peer: 3.3.3.9
Type: IBGP link
BGP version 4, remote router ID 3.3.3.9
BGP current state: Established, Up for
BGP current event: KATimerExpired
BGP last state: OpenConfirm
Port: Local - 179
Configured: Active Hold Time: 180 sec
Received : Active Hold Time: 180 sec
Negotiated: Active Hold Time: 180 sec
Peer optional capabilities:
Peer support bgp multi-protocol extended
Peer support bgp route refresh capability
Address family IPv4 Unicast: advertised and received
Address family L2VPN: advertised and received
Received: Total 26 messages, Update messages 2
Sent: Total 28 messages, Update messages 2
Maximum allowed prefix number: 150000
Threshold: 75%
Minimum time between advertisement runs is 15 seconds
Peer Preferred Value: 0
BFD: Enabled
Routing policy configured:
No routing policy is configured
Table 1-3 display bgp l2vpn peer verbose command output description
Field
Peer
Local
Type
BGP current state
BGP current event
BGP last state
Port
Configured
Received
Negotiated
Peer optional capabilities:
Peer support bgp multi-protocol extended
Peer support bgp route refresh capability
Address family IPv4 Unicast
Address family L2VPN
Local: 2.2.2.9
Remote - 1034
IP address of the peer
IP address of the local router
BGP type
Current status of the BGP session
Current event of the BGP session
Last status of the BGP session
Ports used by the BGP session, one is local or
the other remote
Settings of the local timers
Settings of the remote timers
Negotiated settings of the timers
Optional peer capabilities, including the support
for BGP multicast protocol extension and the
support for BGP route refreshing
IPv4 unicast address family capability
L2VPN address family
1-6
00:21:15
Keep Alive Time:60 sec
Description
