RM0366
IR(3:0)
1010
1011
1000
Address A(3:2) value
0x0
0x4
Table 115. JTAG debug port data registers (continued)
Data register
Debug port access register
This initiates a debug port and allows access to a debug port register.
– When transferring data IN:
Bits 34:3 = DATA[31:0] = 32-bit data to transfer for a write request
Bits 2:1 = A[3:2] = 2-bit address of a debug port register.
Bit 0 = RnW = Read request (1) or write request (0).
DPACC
– When transferring data OUT:
[35 bits]
Bits 34:3 = DATA[31:0] = 32-bit data which is read following a read
request
Bits 2:0 = ACK[2:0] = 3-bit Acknowledge:
010 = OK/FAULT
001 = WAIT
OTHER = reserved
Refer to
Access port access register
Initiates an access port and allows access to an access port register.
– When transferring data IN:
Bits 34:3 = DATA[31:0] = 32-bit data to shift in for a write request
Bits 2:1 = A[3:2] = 2-bit address (sub-address AP registers).
Bit 0 = RnW= Read request (1) or write request (0).
– When transferring data OUT:
Bits 34:3 = DATA[31:0] = 32-bit data which is read following a read
APACC
request
[35 bits]
Bits 2:0 = ACK[2:0] = 3-bit Acknowledge:
010 = OK/FAULT
001 = WAIT
OTHER = reserved
There are many AP Registers (see AHB-AP) addressed as the
combination of:
– The shifted value A[3:2]
– The current value of the DP SELECT register
Abort register
ABORT
– Bits 31:1 = Reserved
[35 bits]
– Bit 0 = DAPABORT: write 1 to generate a DAP abort.
Table 116. 32-bit debug port registers addressed
through the shifted value A[3:2]
00 Reserved, must be kept at reset value.
DP CTRL/STAT register. Used to:
– Request a system or debug power-up
01 – Configure the transfer operation for AP accesses
– Control the pushed compare and pushed verify operations.
– Read some status flags (overrun, power-up acknowledges)
Table 116 for a description of the A(3:2) bits
Description
RM0366 Rev 5
Debug support (DBG)
Details
845/874
