Note: If ADC measurements are done using an output format other than 12 bit right-aligned, all the
parameters must first be converted to a compatible format before the calculation is done.
12.4 ADC interrupts
For each ADC, an interrupt can be generated:
•
After ADC power-up, when the ADC is ready (flag ADRDY)
•
On the end of any conversion for regular groups (flag EOC)
•
On the end of a sequence of conversion for regular groups (flag EOS)
•
On the end of any conversion for injected groups (flag JEOC)
•
On the end of a sequence of conversion for injected groups (flag JEOS)
•
When an analog watchdog detection occurs (flag AWD1, AWD2 and AWD3)
•
When the end of sampling phase occurs (flag EOSMP)
•
When the data overrun occurs (flag OVR)
•
When the injected sequence context queue overflows (flag JQOVF)
Separate interrupt enable bits are available for flexibility.
ADC ready
End of conversion of a regular group
End of sequence of conversions of a regular group
End of conversion of a injected group
End of sequence of conversions of an injected group
Analog watchdog 1 status bit is set
Analog watchdog 2 status bit is set
Analog watchdog 3 status bit is set
End of sampling phase
Overrun
Injected context queue overflows
Table 41. ADC interrupts per each ADC
Interrupt event
RM0366 Rev 5
Analog-to-digital converters (ADC)
Event flag Enable control bit
ADRDY
EOC
EOS
JEOC
JEOS
AWD1
AWD2
AWD3
EOSMP
OVR
JQOVF
ADRDYIE
EOCIE
EOSIE
JEOCIE
JEOSIE
AWD1IE
AWD2IE
AWD3IE
EOSMPIE
OVRIE
JQOVFIE
