Advanced-control timer (TIM1)
Bits 24, 14:12 OC4M[3:0]: Output compare 4 mode
Refer to OC3M[3:0] description.
Bit 11 OC4PE: Output compare 4 preload enable
Refer to OC1PE description.
Bit 10 OC4FE: Output compare 4 fast enable
Refer to OC1FE description.
Bits 9:8 CC4S[1:0]: Capture/Compare 4 selection
This bit-field defines the direction of the channel (input/output) as well as the used input.
00: CC4 channel is configured as output
01: CC4 channel is configured as input, IC4 is mapped on TI4
10: CC4 channel is configured as input, IC4 is mapped on TI3
11: CC4 channel is configured as input, IC4 is mapped on TRC. This mode is working only if
an internal trigger input is selected through TS bit (TIMx_SMCR register)
Note: CC4S bits are writable only when the channel is OFF (CC4E = '0' in TIMx_CCER).
Bit 7 OC3CE: Output compare 3 clear enable
Refer to OC1CE description.
Bits 16, 6:4 OC3M[3:0]: Output compare 3 mode
Refer to OC1M[3:0] description.
Bit 3 OC3PE: Output compare 3 preload enable
Refer to OC1PE description.
Bit 2 OC3FE: Output compare 3 fast enable
Refer to OC1FE description.
Bits 1:0 CC3S[1:0]: Capture/Compare 3 selection
This bit-field defines the direction of the channel (input/output) as well as the used input.
00: CC3 channel is configured as output
01: CC3 channel is configured as input, IC3 is mapped on TI3
10: CC3 channel is configured as input, IC3 is mapped on TI4
11: CC3 channel is configured as input, IC3 is mapped on TRC. This mode is working only if
an internal trigger input is selected through TS bit (TIMx_SMCR register)
Note: CC3S bits are writable only when the channel is OFF (CC3E = '0' in TIMx_CCER).
17.4.11
TIM1 capture/compare enable register
(TIM1_CCER)
Address offset: 0x20
Reset value: 0x0000 0000
31
30
29
Res.
Res.
Res.
Res.
15
14
13
CC4NP
Res.
CC4P
CC4E
rw
rw
Bits 31:22 Reserved, must be kept at reset value.
408/874
28
27
26
25
Res.
Res.
Res.
12
11
10
9
CC3NP CC3NE
CC3P
rw
rw
rw
rw
24
23
22
Res.
Res.
Res.
CC6P
8
7
6
CC3E
CC2NP CC2NE
CC2P
rw
rw
rw
RM0366 Rev 5
21
20
19
18
CC6E
Res.
Res.
rw
rw
5
4
3
2
CC2E
CC1NP CC1NE
rw
rw
rw
rw
RM0366
17
16
CC5P
CC5E
rw
rw
1
0
CC1P
CC1E
rw
rw
