RM0366
8.4.11
GPIO port bit reset register (GPIOx_BRR) (x = A to D and F)
Address offset: 0x28
Reset value: 0x0000 0000
31
30
29
Res.
Res.
Res.
15
14
13
BR15
BR14
BR13
BR12
w
w
w
Bits 31:16 Reserved, must be kept at reset value.
Bits 15:0 BR[15:0]: Port x reset IO pin y (y = 15 to 0)
28
27
26
25
Res.
Res.
Res.
Res.
12
11
10
9
BR11
BR10
BR9
w
w
w
w
These bits are write-only. A read to these bits returns the value 0x0000.
0: No action on the corresponding ODx bit
1: Reset the corresponding ODx bit
24
23
22
Res.
Res.
Res.
8
7
6
BR8
BR7
BR6
w
w
w
RM0366 Rev 5
General-purpose I/Os (GPIO)
21
20
19
18
Res.
Res.
Res.
Res.
5
4
3
2
BR5
BR4
BR3
BR2
w
w
w
w
17
16
Res.
Res.
1
0
BR1
BR0
w
w
141/874
