Digital-to-analog converter (DAC1)
Bits 31:12 Reserved, must be kept at reset value.
Bits 11:0 DACC1DOR[11:0]: DAC channel1 data output
These bits are read-only, they contain data output for DAC channel1.
13.9.7
DAC status register (DAC_SR)
Address offset: 0x34
Reset value: 0x0000 0000
31
30
29
Res.
Res.
Res.
15
14
13
Res.
Res.
DMAUDR1
rc_w1
Bits 31:14 Reserved, must be kept at reset value.
Bit 13 DMAUDR1: DAC channel1 DMA underrun flag
This bit is set by hardware and cleared by software (by writing it to 1).
0: No DMA underrun error condition occurred for DAC channel1
1: DMA underrun error condition occurred for DAC channel1 (the currently selected trigger is
driving DAC channel1 conversion at a frequency higher than the DMA service capability rate)
Bits 12:0 Reserved, must be kept at reset value.
290/874
28
27
26
25
Res.
Res.
Res.
Res.
12
11
10
9
Res.
Res.
Res.
Res.
24
23
22
Res.
Res.
Res.
8
7
6
Res.
Res.
Res.
RM0366 Rev 5
21
20
19
18
Res.
Res.
Res.
Res.
5
4
3
2
Res.
Res.
Res.
Res.
RM0366
17
16
Res.
Res.
1
0
Res.
Res.
