Advanced-control timer (TIM1)
17.4.17
TIM1 capture/compare register 2
(TIM1_CCR2)
Address offset: 0x38
Reset value: 0x0000
15
14
13
rw
rw
rw
Bits 15:0 CCR2[15:0]: Capture/Compare 2 value
17.4.18
TIM1 capture/compare register 3
(TIM1_CCR3)
Address offset: 0x3C
Reset value: 0x0000
15
14
13
rw
rw
rw
Bits 15:0 CCR3[15:0]: Capture/Compare value
If channel CC3 is configured as output: CCR3 is the value to be loaded in the actual
capture/compare 3 register (preload value).
It is loaded permanently if the preload feature is not selected in the TIMx_CCMR2 register
(bit OC3PE). Else the preload value is copied in the active capture/compare 3 register when
an update event occurs.
The active capture/compare register contains the value to be compared to the counter
TIMx_CNT and signalled on OC3 output.
If channel CC3 is configured as input: CCR3 is the counter value transferred by the last
input capture 3 event (IC3). The TIMx_CCR3 register is read-only and cannot be
programmed.
414/874
12
11
10
9
rw
rw
rw
rw
If channel CC2 is configured as output: CCR2 is the value to be loaded in the actual
capture/compare 2 register (preload value).
It is loaded permanently if the preload feature is not selected in the TIMx_CCMR1 register
(bit OC2PE). Else the preload value is copied in the active capture/compare 2 register when
an update event occurs.
The active capture/compare register contains the value to be compared to the counter
TIMx_CNT and signaled on OC2 output.
If channel CC2 is configured as input: CCR2 is the counter value transferred by the last
input capture 2 event (IC2). The TIMx_CCR2 register is read-only and cannot be
programmed.
12
11
10
9
rw
rw
rw
rw
8
7
6
CCR2[15:0]
rw
rw
rw
8
7
6
CCR3[15:0]
rw
rw
rw
RM0366 Rev 5
5
4
3
2
rw
rw
rw
rw
5
4
3
2
rw
rw
rw
rw
RM0366
1
0
rw
rw
1
0
rw
rw
