General-purpose timer (TIM2)
Bit 1 CC1IF: Capture/compare 1 interrupt flag
This flag is set by hardware. It is cleared by software (input capture or output compare mode)
or by reading the TIMx_CCR1 register (input capture mode only).
0: No compare match / No input capture occurred
1: A compare match or an input capture occurred
If channel CC1 is configured as output: this flag is set when the content of the counter
TIMx_CNT matches the content of the TIMx_CCR1 register. When the content of
TIMx_CCR1 is greater than the content of TIMx_ARR, the CC1IF bit goes high on the
counter overflow (in up-counting and up/down-counting modes) or underflow (in down-
counting mode). There are 3 possible options for flag setting in center-aligned mode, refer to
the CMS bits in the TIMx_CR1 register for the full description.
If channel CC1 is configured as input: this bit is set when counter value has been captured
in TIMx_CCR1 register (an edge has been detected on IC1, as per the edge sensitivity
defined with the CC1P and CC1NP bits setting, in TIMx_CCER).
Bit 0 UIF: Update interrupt flag
This bit is set by hardware on an update event. It is cleared by software.
0: No update occurred
1: Update interrupt pending. This bit is set by hardware when the registers are updated:
At overflow or underflow and if UDIS=0 in the TIMx_CR1 register.
When CNT is reinitialized by software using the UG bit in TIMx_EGR register, if URS=0 and
UDIS=0 in the TIMx_CR1 register.
When CNT is reinitialized by a trigger event (refer to the synchro control register description),
if URS=0 and UDIS=0 in the TIMx_CR1 register.
18.4.6 TIM2 event generation register (TIM2_EGR)
Address offset: 0x14
Reset value: 0x0000
15 14 13
Res. Res. Res. Res.
Bits 15:7 Reserved, must be kept at reset value.
Bit 6 TG: Trigger generation
Bit 5 Reserved, must be kept at reset value.
Bit 4 CC4G: Capture/compare 4 generation
Bit 3 CC3G: Capture/compare 3 generation
480/874
12 11 10 9
Res. Res. Res.
This bit is set by software in order to generate an event, it is automatically cleared by
hardware.
0: No action
1: The TIF flag is set in TIMx_SR register. Related interrupt or DMA transfer can occur if
enabled.
Refer to CC1G description
Refer to CC1G description
8 7 6
Res. Res. TG
w
RM0366 Rev 5
5 4 3 2
Res. CC4G CC3G CC2G
w w w
RM0366
1 0
CC1G UG
w w
